75W LED Sport Fields Flood Light IP66 Waterproof With Die Casting Aluminum Shell

Name: 75W LED Sport Fields Flood Light IP66 Waterproof With Die Casting Aluminum Shell
Brand: SUNLUXX
Price: 129.31 USD

China 75W LED Sport Fields Flood Light IP66 Waterproof With Die Casting Aluminum Shell wholesale

Brand Name : SUNLUXX

Model Number : FAL-75W

Certification : CE RoHs

Place of Origin : China

MOQ : 1

Price : US$129.31/PC , EXW price

Payment Terms : T/T, Western Union

Supply Ability : 6000 Pieces per Month

Delivery Time : 3-5 work days

Packaging Details : 54cm*46cm*19cm/2pcs/carton

Wattage : 75W

Lumen : 10500lm

Input Voltage : 90-305VAC

LED Chip : Nichia 3030

IP Class : IP66

Driver : MEANWELL

Power Factor : > 0.95

IK : 10

Working Temp. : -40℃ - -+45℃

Storage Temp. : -40℃ - -+85℃

Color : Grey

Mounting Way : Adjustable Strong Bracket

Contact Now

IP66 Die Casting Aluminum 75W LED Stadium Flood Light IK10 Area Flood Light , 140LM Per Watt

Features

1. Universal voltage 90-305VAC available

2. Excellent optical design, greatly improve the light utilization and evenness

3. IP65 rating for outdoor use

4. Using well-know high quality NICHIA LED chips, MEANWELL driver. Reliable and long life. Ferrari idea design, IP66, IK10 protection, strong wind resistance, various beam angle options, wide applications.

5. 75W/100W/150W/200W/240W for your options.

6. Instant start, no noise, no flickering

7. mounting brackets with adjustable angle 180 degree

8. We provide 5 years warranty

Technical Data

Power		75W
Input Voltage		90 - 305VAC
Input Current		0.68A@220VAC
PF		>0.9@220VAC
DC Output Voltage		48V
DC Output Current		2.9A
Dimming (Optional)		3 in one dimming(PMW, 1-10V,Resistor), DALI
CCT		4000k, 5000k, 5700K, 3000K and 2700K can be customized
Ra>80,5000K	Typical Flux	19500lm±10%
	Efficiency	130lm/W±10%
Ra>70,5000K	Typical Flux	21000lm±10%
	Efficiency	140lm/W±10%
LED Brand		NICHIA 3030
Light Type		Asymmetric and symmetric polarized light
Operation Temp.		-40 ℃ to + 45 ℃
Storage Temp.		-40 ℃ to + 85 ℃
Lifespan		45℃ , 50,000 hours
IP Class		66
IK Class		10
Lamp Body Color		Grey or as customized
Product Size(mm)		33037350
Net Weight(kg)		4.76
Packing size(mm)		540460190
Gross Weight(kg)		13.5
Product Quantity Per Carton		2pcs
Installation Method		Bracket Mount

75W LED Sport Fields Flood Light IP66 Waterproof With Die Casting Aluminum Shell

Beam Angle

Accessories

Light Distribusion Curve

Installation Manual

Applications

Side Walk Lighting, Garden Lighting,Park Lighting,Billboard Lighting,Landscape Lighting,Building Lighting,Stadium Lighting.

75W LED Sport Fields Flood Light IP66 Waterproof With Die Casting Aluminum Shell
